New Holland
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 7,626 lb |
|---|---|
| Max Speed | 11.4 mph |
| Fuel Capacity | 21.6 gal |
| Hydraulic System Fluid Capacity | 15.1 gal |
| Tire Size | 12x16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 30 A |
| Engine Oil Fluid Capacity | 3.9 gal |
| Cooling System Fluid Capacity | 4.5 gal |
| Chain Box Fluid Capacity - each side | 3.0 gal |
| Operating Speed | 7.0 mph |
Engine
| Engine Model | 445M2 |
|---|---|
| Displacement | 275 in³ |
| Power Measured @ | 2,300 rpm |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 21.9 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | New Holland double acting |
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Height - Top of Cab | 80 in |
| Wheelbase | 52 in |
| Width Over Tires | 72 in |
| Reach at Max Lift and Dump | 32 in |
| Length with Bucket | 146 in |
| Clearance at Max Lift and Dump | 11 in |
Loader
| Bucket Capacity | 0.99 yd³ |
|---|---|
| Operating Load Rating | 2,800 lb |
| Tipping Angle | 5,600 ° |
| Breakout Force | 7,670 psi |
