New Holland
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
47 data points
Operating Specifications
| Fuel Capacity | 66.9 gal |
|---|---|
| Hydraulic System Fluid Capacity | 36.8 gal |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 3.6 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 70 A |
| Front Axle/Diff Fluid Capacity | 8.1 gal |
| Rear Axle/Diff Fluid Capacity | 7.3 gal |
| Cooling System Fluid Capacity | 9.8 gal |
| Transmission Fluid Capacity | 62.4 gal |
Engine
| Engine Model | 668TA |
|---|---|
| Displacement | 409 in³ |
| Power Measured @ | 2,000 rpm |
| Gross Power | 181.0 hp |
| Net Power | 170.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,400 rpm |
| Engine Make | New Holland |
| Stroke | 52 in |
| Bore | 4 in |
| Torque Rise | 25.0 % |
| Air cleaner | Dry type elements |
| Emissions Certification | Tier 2 |
Hydraulic System
| Pump Flow Capacity | 22.7 gal/min |
|---|---|
| Raise Time | 5.6 s |
| Lower Time | 3.3 s |
| Dump Time | 2.4 s |
| Relief Valve Setting | — |
| Pump Type | Piston pump |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 133 in |
| Wheelbase | 128 in |
| Width Over Tires | 103 in |
| Length with Bucket on Ground | 301 in |
| Hinge Pin - Max Height | 157 in |
Transmission
| Max Speed - Forward | 23.5 mph |
|---|---|
| Max Speed - Reverse | 16.0 mph |
| Transmission Type | Power shift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 3.30 yd³ |
|---|---|
| Bucket Capacity - struck | 2.80 yd³ |
| Dump Clearance at Max Raise | 117 in |
| Breakout Force | 31,435 lb |
| Bucket Width | 107 in |
| Digging depth | 4 in |
