New Holland
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
New Holland
LW190
- Operating Weight
- 35,935 lb
- Bucket Capacity - heaped
- 4.20 yd³
- Gross Power
- 194.0 hp
- Net Power
- 205.0 hp
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 35,935 lb |
|---|---|
| Fuel Capacity | 63.5 gal |
| Tire Size | 23.5x25 XHA |
| Hydraulic System Fluid Capacity | 39.7 gal |
| Static Tipping Weight | 31,085 lb |
| Operating Voltage | 24 V |
| Turning Radius | 257 in |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | 6CT 8.3 |
|---|---|
| Displacement | 507 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 194.0 hp |
| Net Power | 205.0 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 133 in |
| Wheelbase | 126 in |
| Width Over Tires | 149 in |
| Reach at Max Lift and Dump | 43 in |
| Length with Bucket on Ground | 316 in |
Transmission
| Max Speed - Forward | 23.4 mph |
|---|---|
| Max Speed - Reverse | 24.9 mph |
| Transmission Type | countershaft automatic |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 4.20 yd³ |
|---|---|
| Dump Clearance at Max Raise | 118 in |
| Breakout Force | 35,935 lb |
| Bucket Width | 115 in |
