New Holland

T9.020

Tractor

Operating Weight
39,599 lb
Displacement
549 in³
Power Measured @
1,800 rpm
Gross Power
368.0 hp
All tractors
New Holland T9.020 Tractor
1 / 5
Image 1 of 5
Image: tractors.fandom.com

Specifications

30 data points

Operating Specifications

Operating Specifications specifications
Operating Weight39,599 lb
Fuel Capacity200.0 gal
3 Point Hitch Lift Capacity @ 24 inches15,668 lb
3 Point Hitch TypeCat IV-N/III
Turning Radius181 in
Alternator Supplied Amperage150 A
Operating Voltage12 V
Cooling System Fluid Capacity12.5 gal
Engine Oil Capacity7.4 gal
Drawbar Static Vertical Load Rating4,500 lb

Engine

Engine specifications
Displacement549 in³
Power Measured @1,800 rpm
Gross Power368.0 hp
Net Power335.0 hp
AspirationTurbocharged air to air after cooled
Torque Rise35.0 %

Hydraulic System

Hydraulic System specifications
Pump Flow Capacity40.0 gal/min
Number of Remote Control Valves4

Dimensions

Dimensions specifications
Height - Top of Cab143 in
Wheelbase139 in
Overall Length23 in
Tire Size20.8R42
Width Outside Frame37 in

Transmission

Transmission specifications
Number of Forward Gears16
Transmission Typepowershift
Number of Reverse Gears2

Production

Production specifications
SeriesT9000 Series
Years Manufactured2,007 – 2,010

Axles

Axles specifications
Final DriveInboard 3-planetary
Axle Diameter4 in
