New Holland
TJ375
- Operating Weight
- 37,610 lb
- Displacement
- 909 in³
- Power Measured @
- 1,000 rpm
- Gross Power
- 375.0 hp
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 37,610 lb |
|---|---|
| Fuel Capacity | 300.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 19,500 lb |
| 3 Point Hitch Type | III IVN |
| Alternator Supplied Amperage | 135 A |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 21.2 gal |
| Engine Oil Capacity | 13.0 gal |
| DEF tank capacity | 43.0 gal |
Engine
| Displacement | 909 in³ |
|---|---|
| Power Measured @ | 1,000 rpm |
| Gross Power | 375.0 hp |
| Net Power | 2,000.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Engine Make | New Holland |
| PTO Power | 330.0 hp |
| Stroke | 7 in |
| Bore | 5 in |
| Torque | 1,380 lb-ft |
Hydraulic System
| Pump Flow Capacity | 35.0 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Hydraulic System Type | Closed center load sensing |
Dimensions
| Wheelbase | 154 in |
|---|---|
| Overall Length | 317 in |
Transmission
| Max Speed - Reverse | 8.3 mph |
|---|---|
| Max Speed - Forward | 19.3 mph |
| Number of Forward Gears | 16 |
| Transmission Type | Full power shift |
| Number of Reverse Gears | 2 |
Production
| Series | TJ I Series |
|---|---|
| Years Manufactured | 2,002 – 2,005 |
