New Holland
John Deere
8RT 335
Tractor
17 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 45,600 lb |
|---|---|
| Fuel Capacity | 300.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 19,620 lb |
| 3 Point Hitch Type | IVN |
| Alternator Supplied Amperage | 175 A |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 21.2 gal |
| Engine Oil Capacity | 8.2 gal |
| Front Tire Size | 20.8R42 |
| Rear Tire Size | 20.8R42 |
Engine
| Displacement | 787 in³ |
|---|---|
| Gross Power | 380.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged |
| Engine Make | Iveco |
| PTO Power | 380.0 hp |
| Stroke | 6 in |
| Bore | 5 in |
Hydraulic System
| Pump Flow Capacity | 33.0 gal/min |
|---|---|
| Number of Remote Control Valves | — |
| Relief Valve Pressure | 2,000 psi |
| Hydraulic System Type | Closed center load sensing |
Dimensions
| Height - Top of Cab | 150 in |
|---|---|
| Wheelbase | 154 in |
| Overall Length | 298 in |
Transmission
| Number of Forward Gears | 16 |
|---|---|
| Transmission Type | Full power shift |
| Number of Reverse Gears | 2 |
Production
| Series | TJ II Series |
|---|---|
| Years Manufactured | 2,006 – 2,007 |
