New Holland
Rostselmash
Niva-Effect
Combine
24 specifications
1 / 5
Image 1 of 5
Specifications
35 data points
Operating Specifications
| Operating Weight w/o Attachment | 22,245 lb |
|---|---|
| Fuel Capacity | 78.0 gal |
Engine
| Engine Model | 3208 |
|---|---|
| Displacement | 636 in³ |
| Power Measured @ | 2,630 rpm |
| Number of Cylinders | 8 |
| Engine Make | Caterpillar |
| Power Boost Power | 175.0 hp |
Dimensions
| Wheelbase | 131 in |
|---|---|
| Transport Width | 166 in |
| Transport Height | 154 in |
| Transport Length | 358 in |
| Turning Radius | 248 in |
| Unloader clearance | 150 in |
| Unloader reach | 115 in |
Tires & Wheels
| Rear Tires Size | 11 x 16 F2 6-ply |
|---|---|
| Front Tires Size | 28L x 26 R1 10-ply |
Cleaning System
| Cleaning Fan Speed - High | 1,055 rpm |
|---|---|
| Cleaning Fan Speed - Low | 540 rpm |
| Cleaning system width | 37 in |
Grain Handling
| Grain Tank Capacity | 1,908.4 gal |
|---|---|
| Unloading Discharge Height | 154 in |
| Unloading auger diameter | 12 in |
Threshing
| Rotor Diameter | 18 in |
|---|---|
| Rotor Length | 84 in |
| Rotor Speed - High | 1,790 rpm |
| Rotor Speed - Low | 790 rpm |
| Concave Area | 1,166 in³ |
| Beater Grate Area | 628 in³ |
| Rotor Type | Closed tube 3 stage; inlet thresh and separate; 4 parallel rasp bars front section 2 separating bars rear section |
HEADER
| Width - Table | 150 in |
|---|---|
| Auger diameter | 24 in |
| HEADER Type | Centre feed |
| Conveyor speed | 14,760.0 mph |
| Lowering time | Adjustable |
