Rostselmash
Kartar
4000
Combine
13 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight w/o Attachment | 14,632 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
Engine
| Engine Model | D-260.1 |
|---|---|
| Aspiration | turbocharged |
| Power | 152.9 hp |
Dimensions
| Wheelbase | 141 in |
|---|---|
| Overall Length | 431 in |
| Width Over Tires | 163 in |
| Height to Top of Isomount Cab | 157 in |
Cleaning System
| Total Cleaning Area | 3,751 in³ |
|---|---|
| Cleaning Fan Speed - High | 723 rpm |
| Cleaning Fan Speed - Low | 432 rpm |
Feeding
| Conveyor Width | 211 in |
|---|---|
| Conveyor Speed | 42 rpm |
Grain Handling
| Grain Tank Capacity | 793.1 gal |
|---|---|
| Unloading Discharge Height | 103 in |
Separating
| Separating Area | 6,727 in³ |
|---|---|
| Separator Type | 4 key straw walker |
| Separator Length | 143 in |
Threshing
| Rotor Diameter | 24 in |
|---|---|
| Rotor Length | 47 in |
| Rotor Speed - High | 1,260 rpm |
| Rotor Speed - Low | 743 rpm |
| Concave Area | 1,442 in³ |
