New Holland
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Fuel Capacity | 65.0 gal |
|---|---|
| Tire Size | 235R25 |
| Hydraulic System Fluid Capacity | 47.6 gal |
| Operating Voltage | 24 V |
| Engine Oil Fluid Capacity | 4.0 gal |
| Rear Axle Oscillation | 24 ° |
| Alternator Supplied Amperage | 65 A |
| Transmission Fluid Capacity | 9.0 gal |
Engine
| Power Measured @ | 1,800 rpm |
|---|---|
| Gross Power | 195.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,300 rpm |
| Max torque ISO TR14396 | 701 lb-ft |
Hydraulic System
| Pump Flow Capacity | 54.5 gal/min |
|---|---|
| Raise Time | 5.2 s |
| Lower Time | 2.5 s |
| Dump Time | 1.2 s |
| Pump Type | Tandem Variable |
Dimensions
| Ground Clearance | 16 in |
|---|---|
| Height - Top of Cab | 133 in |
| Wheelbase | 128 in |
| Width Over Tires | 104 in |
| Reach at Max Lift and Dump | 46 in |
| Length with Bucket on Ground | 301 in |
| Hinge Pin - Max Height | 157 in |
Transmission
| Max Speed - Forward | 23.0 mph |
|---|---|
| Max Speed - Reverse | 16.2 mph |
| Transmission Type | Powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 3.60 yd³ |
|---|---|
| Dump Clearance at Max Raise | 117 in |
| Breakout Force | 31,385 lb |
| Bucket Width | 108 in |
