New Holland
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
41 data points
Operating Specifications
| Operating Weight | 39,419 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Tire Size | 23.5-25 GP-2B |
| Hydraulic System Fluid Capacity | 39.7 gal |
| Static Tipping Weight | 31,967 lb |
| Operating Voltage | 24 V |
| Turning Radius | 257 in |
| Engine Oil Fluid Capacity | 4.0 gal |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 8.5 gal |
| Rear Axle/Diff Fluid Capacity | 8.5 gal |
| Cooling System Fluid Capacity | 11.9 gal |
| Transmission Fluid Capacity | 6.9 gal |
Engine
| Engine Model | CNH NEF 6CRTAA |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 201.2 hp |
| Number of Cylinders | 6 |
| Aspiration | turbo aftercooler |
Hydraulic System
| Pump Flow Capacity | 85.9 gal/min |
|---|---|
| Raise Time | 6.2 s |
| Lower Time | 3.1 s |
| Dump Time | 1.4 s |
| Relief Valve Setting | 3,046 psi |
| Pump Type | Sealed system with anticavitation and relief valves |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 135 in |
| Wheelbase | 126 in |
| Width Over Tires | 109 in |
| Reach at Max Lift and Dump | 47 in |
| Length with Bucket on Ground | 320 in |
| Hinge Pin - Max Height | 161 in |
Transmission
| Max Speed - Forward | 22.8 mph |
|---|---|
| Max Speed - Reverse | 15.6 mph |
| Transmission Type | PowerShift CounterShaft |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 4.20 yd³ |
|---|---|
| Breakout Force | 3,776,790 lb |
| Bucket Width | 118 in |
