New Holland
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
42 data points
Operating Specifications
| Operating Weight | 47,377 lb |
|---|---|
| Fuel Capacity | 85.9 gal |
| Tire Size | 23.5-25 GP-2B |
| Hydraulic System Fluid Capacity | 34.4 gal |
| Static Tipping Weight | 37,942 lb |
| Operating Voltage | 24 V |
| Turning Radius | 264 in |
| Engine Oil Fluid Capacity | 6.4 gal |
| Rear Axle Oscillation | 22 ° |
| Alternator Supplied Amperage | 50 A |
| Front Axle/Diff Fluid Capacity | 10.1 gal |
| Rear Axle/Diff Fluid Capacity | 10.1 gal |
| Cooling System Fluid Capacity | 15.9 gal |
| Transmission Fluid Capacity | 10.6 gal |
Engine
| Engine Model | 6CTAA 8.3 |
|---|---|
| Displacement | 507 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 225.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,200 rpm |
Hydraulic System
| Pump Flow Capacity | 94.9 gal/min |
|---|---|
| Raise Time | 6.2 s |
| Lower Time | 3.5 s |
| Dump Time | 1.4 s |
| Relief Valve Setting | 3,046 psi |
| Pump Type | Two gear type with steel case and automatic wear compensation. |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Height - Top of Cab | 138 in |
| Wheelbase | 131 in |
| Width Over Tires | 115 in |
| Reach at Max Lift and Dump | 47 in |
| Length with Bucket on Ground | 331 in |
| Hinge Pin - Max Height | 166 in |
Transmission
| Max Speed - Forward | 24.9 mph |
|---|---|
| Max Speed - Reverse | 27.3 mph |
| Transmission Type | Power-Shift Countershaft |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 5.30 yd³ |
|---|---|
| Bucket Capacity - struck | 4.90 yd³ |
| Breakout Force | 4,114,004 lb |
| Bucket Width | 121 in |
