Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 37,038 lb |
|---|---|
| Tire Size | 23.5x25 |
| Static Tipping Weight | 22,487 lb |
| Turning Radius | 265 in |
Engine
| Engine Model | 6CTA8.3 |
|---|---|
| Displacement | 507 in³ |
| Power Measured @ | 2,300 rpm |
| Net Power | 220.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 133 in |
| Wheelbase | 126 in |
| Width Over Tires | 108 in |
| Reach at Max Lift and Dump | 44 in |
| Length with Bucket on Ground | 317 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Max Speed - Reverse | 14.3 mph |
| Transmission Type | Electrohydrostatic |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 4.00 yd³ |
|---|---|
| Dump Clearance at Max Raise | 124 in |
| Bucket Width | 121 in |
