Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight | 40,786 lb |
|---|---|
| Tire Size | 23.5x25 |
| Static Tipping Weight | 13,228 lb |
| Turning Radius | 289 in |
Engine
| Engine Model | 3306B |
|---|---|
| Displacement | 593 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 234.1 hp |
| Number of Cylinders | 6 |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 133 in |
| Wheelbase | 137 in |
| Width Over Tires | 108 in |
| Reach at Max Lift and Dump | 41 in |
| Length with Bucket on Ground | 329 in |
Transmission
| Max Speed - Forward | 22.4 mph |
|---|---|
| Max Speed - Reverse | 14.3 mph |
| Transmission Type | Electrohydrostatic |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 4.80 yd³ |
|---|---|
| Dump Clearance at Max Raise | 128 in |
| Bucket Width | 127 in |
