Salford
Kartar
4000
Combine
13 specifications
Salford
TC5050
- Operating Weight w/o Attachment
- 16,755 lb
- Fuel Capacity
- 79.3 gal
- Displacement
- 415 in³
- Power
- 170.0 hp
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight w/o Attachment | 16,755 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Transmission Type | hydro |
| Number of Gears | 4 |
Engine
| Engine Model | 6.8 I |
|---|---|
| Displacement | 415 in³ |
| Power Measured @ | 2,100 rpm |
| Power | 170.0 hp |
| Power Boost Power | 175.0 hp |
Dimensions
| Overall Length | 320 in |
|---|---|
| Width Over Tires | 131 in |
Cleaning System
| Total Cleaning Area | 5,069 in³ |
|---|---|
| Cleaning Fan Speed - High | 1,000 rpm |
| Cleaning Fan Speed - Low | 350 rpm |
| Self Leveling | 0 |
Grain Handling
| Grain Tank Capacity | 1,057.5 gal |
|---|---|
| Unloading Speed | 1.8 bu/sec |
Separating
| Separator Type | rotary |
|---|
Threshing
| Rotor Diameter | 24 in |
|---|---|
| Rotor Length | 41 in |
| Rotor Speed - High | 1,070 rpm |
| Rotor Speed - Low | 430 rpm |
