Sam
Apache
AS1220
Sprayer
21 specifications
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Solution Tank Capacity | 1,056.6 gal |
|---|---|
| Rinse Tank Capacity | 79.3 gal |
| Fuel Capacity | 58.2 gal |
| Dry Weight - min | 15,322 lb |
| Hydraulic Fluid Capacity | 26.5 gal |
Engine
| Gross Power | 220.0 hp |
|---|---|
| Number of Cylinders | 6 |
| Aspiration | Turbocharged watercooled |
Dimensions
| Ground Clearance | 39 in |
|---|---|
| Wheelbase | 126 in |
| Overall Length | 24 in |
| Transport Width | 115 in |
| Transport Height | 134 in |
| Tire Size | 13.6/28 |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Transmission Type | Fully hydrostatic 4 wheel drive with 4-speed transmission |
Boom
| Max Boom Width | 946 in |
|---|---|
| Max Adjustable Height | 85 in |
| Min Adjustable Height | 24 in |
| Number of Sections | 7 |
