Scat Trak
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 6,980 lb |
|---|---|
| Max Speed | 6.1 mph |
| Fuel Capacity | 21.6 gal |
| Hydraulic System Fluid Capacity | 17.1 gal |
| Tire Size | 12.00x16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 55 A |
Engine
| Engine Model | 1004.42 |
|---|---|
| Displacement | 258 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 86.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 19.1 gal/min |
|---|
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 80 in |
| Wheelbase | 41 in |
| Width Over Tires | 72 in |
| Reach at Max Lift and Dump | 24 in |
| Length with Bucket | 138 in |
| Clearance at Max Lift and Dump | 95 in |
| Turning Radius from Center - inc bucket | 51 in |
| Turning Radius from Center - machine rear | 64 in |
| Length w/o Bucket | 109 in |
Loader
| Operating Load Rating | 1,875 lb |
|---|---|
| Tipping Angle | 3,750 ° |
