Skyjack
Mec
2591ES
Aerial Lift
22 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Wheelbase | 90 in |
| Overall Length | 139 in |
| Overall Width | 88 in |
| Turning Radius | 248 in |
| Gradeability | 30.0 % |
| Height w/ Rails | 106 in |
| Height w/o Rails | 79 in |
Performance
| Operating Weight | 9,980 lb |
|---|---|
| Max Speed | 3.5 mph |
| Tire Size | 10 x 16.5 |
| Tire Fill/Type | Air Filled |
| Load capacity | 2,000 lb |
Platform
| Max Platform Height | 373 in |
|---|---|
| Platform Inner Length | 134 in |
| Platform Inner Width | 67 in |
| Max Working Height | 444 in |
| Lift Time | 58.0 s |
| Deck Extension | 48 in |
| Lower Time | 44.0 s |
| Platform Height - Lowered | 59,056 in |
