Snorkel
Holland Lift
Q135EL24
Aerial Lift
19 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Engine
| Fuel Type | gas/diesel |
|---|
Dimensions
| Ground Clearance | 10 in |
|---|---|
| Wheelbase | 97 in |
| Overall Length | 21 in |
| Overall Width | 97 in |
| Overall Height - mast lowered | 95 in |
| Stowed Width | 95 in |
| Stowed Height | 94 in |
| Boom Type/Size | ST J ft (0.00 m) |
| Platform Size | 60 in |
Transmission
| 4WD | Std |
|---|
Tires & Wheels
| Tire Size | 12x16.5 |
|---|
Performance
| Operating Weight | 13,499 lb |
|---|---|
| Max Speed | 3.0 mph |
| Tire Size | 12x16.5 |
| Hydraulic System Fluid Capacity | 25.0 gal |
| Tire Fill/Type | pneumatic |
| Fuel Capacity | 20.0 gal |
Capacity
| Platform Capacity | 500 lb |
|---|
Platform
| Max Platform Height | 559 in |
|---|---|
| Max Platform Weight Capacity | 500 lb |
| Platform Inner Length | 60 in |
| Platform Inner Width | 30 in |
| Max Horizontal Reach | 469 in |
