Sunward
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 6,129 lb |
|---|---|
| Max Speed | 8.5 mph |
| Fuel Capacity | 18.5 gal |
| Hydraulic System Fluid Capacity | 13.3 gal |
| Tire Size | 10-16.5 |
| Engine Oil Fluid Capacity | 2.0 gal |
| Cooling System Fluid Capacity | 2.1 gal |
| Chain Box Fluid Capacity - each side | 8.0 gal |
Engine
| Engine Model | 4TNV84T |
|---|---|
| Power Measured @ | 2,800 rpm |
| Gross Power | 53.6 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 27.4 gal/min |
|---|---|
| Relief Valve Pressure | 3,625 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 80 in |
| Wheelbase | 40 in |
| Width Over Tires | 64 in |
| Reach at Max Lift and Dump | 19 in |
| Length with Bucket | 128 in |
| Clearance at Max Lift and Dump | 93 in |
| Turning Radius from Center - inc bucket | 77 in |
| Turning Radius from Center - machine rear | 60 in |
| Length w/o Bucket | 98 in |
Loader
| Bucket Capacity | 0.60 yd³ |
|---|---|
| Operating Load Rating | 1,598 lb |
| Tipping Angle | 3,197 ° |
| Breakout Force | 4,189 psi |
