Sunward
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 7,165 lb |
|---|---|
| Max Speed | 7.9 mph |
| Fuel Capacity | 22.5 gal |
| Hydraulic System Fluid Capacity | 17.2 gal |
| Tire Size | 12-16.5 |
| Engine Oil Fluid Capacity | 3.5 gal |
| Cooling System Fluid Capacity | 2.3 gal |
| Chain Box Fluid Capacity - each side | 8.0 gal |
Engine
| Engine Model | V3300DI |
|---|---|
| Power Measured @ | 2,600 rpm |
| Gross Power | 73.7 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 33.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,626 psi |
| Pump Type | Gear |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 83 in |
| Wheelbase | 44 in |
| Width Over Tires | 74 in |
| Reach at Max Lift and Dump | 25 in |
| Length with Bucket | 142 in |
| Clearance at Max Lift and Dump | 95 in |
| Turning Radius from Center - inc bucket | 86 in |
| Turning Radius from Center - machine rear | 67 in |
| Length w/o Bucket | 109 in |
Loader
| Bucket Capacity | 0.71 yd³ |
|---|---|
| Operating Load Rating | 2,094 lb |
| Tipping Angle | 4,189 ° |
| Breakout Force | 5,357 psi |
