Takeuchi
ASV
PT-70
Compact Track Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 6,813 lb |
|---|---|
| Fuel Capacity | 15.6 gal |
| Hydraulic System Fluid Capacity | 13.2 gal |
Engine
| Engine Model | 4JB1 |
|---|---|
| Displacement | 169 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 61.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow | 18.0 gal/min |
|---|---|
| Relief Valve Pressure | 2,276 psi |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 80 in |
| Reach at Max Lift and Dump | 29 in |
| Width Over Tracks | 61 in |
| Length with Bucket | 131 in |
| Clearance at Max Lift and Dump | 95 in |
| Turning Radius from Center - inc bucket | 7 in |
| Turning Radius from Center - machine rear | 5 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Length of Track on Ground | 46 in |
| Number of Track Rollers per Side | 5 |
Loader
| Tipping Angle | 3,750 ° |
|---|---|
| Operating Load | 1,310 lb |
| Breakout Force | — |
