Terex
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Fuel Capacity | 98.0 gal |
|---|---|
| Tire Size | 18.00 x 25-28PR |
| Alternator Supplied Amperage | — |
Engine
| Engine Model | DD 8V-71T |
|---|---|
| Net Power | 321.0 hp |
Weights
| Empty Weight | 49,500 lb |
|---|---|
| Loaded Weight | 109,500 lb |
Dimensions
| Wheelbase | 143 in |
|---|---|
| Overall Length | 302 in |
| Overall Width | 138 in |
| Overall Height | 154 in |
Transmission
| Max Speed | 34.0 mph |
|---|---|
| Transmission Type | Allison CLBT-5960 |
| Number of Gears - Forward | 5 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 59,993.5 gal |
|---|
Dump
| Rated Payload | 60,000 lb |
|---|---|
| Load Capacity - heaped | 22.90 yd³ |
| Load Capacity - Struck | 19.10 yd³ |
