Terex
Caterpillar
773G
Off-Highway Truck
12 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Fuel Capacity | 479.7 gal |
|---|---|
| Tire Size | 36.00 x 51-50PR |
| Alternator Supplied Amperage | — |
Engine
| Engine Model | DD 16V-149TI |
|---|---|
| Net Power | 1,445.7 hp |
Weights
| Empty Weight | 234,396 lb |
|---|---|
| Loaded Weight | 574,304 lb |
Dimensions
| Wheelbase | 217 in |
|---|---|
| Overall Length | 503 in |
| Overall Width | 247 in |
| Overall Height | 224 in |
Transmission
| Max Speed | 29.9 mph |
|---|---|
| Transmission Type | Diesel-Electric Drive |
| Number of Gears - Forward | 5 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 339,915.8 gal |
|---|
Dump
| Rated Payload | 339,953 lb |
|---|---|
| Load Capacity - heaped | 94.50 yd³ |
| Load Capacity - Struck | 70.20 yd³ |
