773G
Off-Highway Truck
12 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Fuel Capacity | 760.0 gal |
|---|---|
| Tire Size | 36.00R51 Radial |
| Engine Oil Capacity | 52.9 gal |
| Cooling System Fluid Capacity | 92.0 gal |
| Hydraulic System Fluid Capacity | 235.2 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 100 A |
Engine
| Engine Model | 12V 4000 |
|---|---|
| Gross Power | 1,725.0 hp |
| Net Power | 1,575.0 hp |
| Number of Cylinders | 12 |
| Aspiration | 100 amps |
| Rated Engine Speed | 235 rpm |
Weights
| Empty Weight | 256,500 lb |
|---|---|
| Loaded Weight | 596,500 lb |
| Weight Distribution Front - loaded | 32.9 % |
| Weight Distribution Rear - loaded | 67.1 % |
| Weight Distribution Front - empty | 50.8 % |
| Weight Distribution Rear - empty | 49.2 % |
Dimensions
| Wheelbase | 217 in |
|---|---|
| Overall Length | 516 in |
| Overall Width | 288 in |
| Overall Height | 269 in |
| Dump Height | 466 in |
| Dump Ground Clearance | 64 in |
Transmission
| Max Speed | 35.1 mph |
|---|
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 339,963.0 gal |
|---|
Dump
| Dump Angle | 45 ° |
|---|---|
| Raise Time | 19.0 s |
| Lower Time | 12.0 s |
| Load Capacity - heaped | 128.19 yd³ |
| Load Capacity - Struck | 81.09 yd³ |
