Terex
PR950 4-Tracks
- Operating Weight - Full Load
- 93,000 lb
- Cutting Width
- 86 in
- Displacement
- 1,404 in³
- Gross Power
- 950.0 hp
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Operating Weight - Full Load | 93,000 lb |
|---|---|
| Operating Speed | 1.9 mph |
| Travel Speed | 3.4 mph |
| Fuel Capacity | 425.1 gal |
| Water Spray System Fluid Capacity | 1,379.6 gal |
| Shipping Weight - Empty | 78,000 lb |
| Hydraulic System Fluid Capacity | 125.0 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | QSK-23 |
|---|---|
| Displacement | 1,404 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 950.0 hp |
| Number of Cylinders | 6 |
Dimensions
| Shipping Height | 126 in |
|---|---|
| Shipping Width | 110 in |
| Operating Length | 667 in |
Track
| Number of Track Units | 4 |
|---|
Conveyor System
| Discharge Conveyor Width | 42 in |
|---|---|
| Collecting Conveyor Width | 42 in |
| Discharge Conveyor Swing (R/L) | 60 ° |
Rotary Cutter
| Cutting Width | 86 in |
|---|---|
| Cutting Depth | 15 in |
