Terex

RH40FHD

Mini Excavator

Gross Power
700.0 hp
Net Power
665.0 hp
All mini excavators
Terex RH40FHD Mini Excavator
1 / 5
Image 1 of 5
Image: tractorhouse.com

Specifications

51 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity435.9 gal
Hydraulic System Fluid Capacity501.9 gal
Operating Voltage24 V
Alternator Supplied Amperage175 A
Swing Speed6 rpm

Engine

Engine specifications
Engine ModelC 18
Displacement1,105 in³
Power Measured @1,800 rpm
Gross Power700.0 hp
Net Power665.0 hp
Aspirationturbocharged

Dimensions

Dimensions specifications
Height - Top of Cab226 in
Length of Track on Ground185 in
Upper Structure Ground Clearance69 in
Length of Tracks238 in
Height of Tracks62 in

Undercarriage

Undercarriage specifications
Track Gauge150 in
Max Travel Speed1.5 mph
Number of Upper Rollers1
Loading Shovel Operating Weight237,217 lb
Loading Shovel Shoe Width24 in
Loading Shovel Ground Pressure25 psi
Number of Lower Rollers8
Backhoe Shoe Width 120 in
Backhoe Operating Weight - Shoe 1233,359 lb
Backhoe Ground Pressure - Shoe 129 psi
Number of Track Shoes per Side48
Tail Swing Radius169 in
Backhoe Shoe Width 224 in
Backhoe Ground Pressure - Shoe 225 psi
Backhoe Operating Weight - Shoe 2236,336 lb
Backhoe Shoe Width 330 in
Backhoe Ground Pressure - Shoe 320 psi
Backhoe Operating Weight - Shoe 3239,312 lb

Bucket

Bucket specifications
Reference Bucket Capacity7.90 yd³
Maximum Bucket Capacity9.19 yd³
Minimum Bucket Capacity7.90 yd³

Loading Shovel

Loading Shovel specifications
Max Dig Depth83 in
Max Dig Reach414 in
Max Cutting Height430 in
Max Dump Height347 in
Loading ShovelBoom 16'7" (5050mm)/Stick 11'8" (3550mm)
Height to Top of Boom - shovel221 in

Backhoe Boom / Stick 1

Backhoe Boom / Stick 1 specifications
Max Dig Depth236 in
Max Cutting Height493 in
Max Dump Height350 in
Max Reach on Ground476 in

Backhoe Boom / Stick 2

Backhoe Boom / Stick 2 specifications
Max Dig Depth288 in
Max Cutting Height504 in
Max Dump Height347 in
Max Reach on Ground521 in
