Terex

RH40FLC

Mini Excavator

Gross Power
700.0 hp
Net Power
665.0 hp
All mini excavators
Terex RH40FLC Mini Excavator
1 / 5
Image 1 of 5
Image: lectura-specs.com

Specifications

42 data points

Operating Specifications

Operating Specifications specifications
Fuel Capacity435.9 gal
Hydraulic System Fluid Capacity501.9 gal
Operating Voltage24 V
Alternator Supplied Amperage175 A
Swing Speed6 rpm

Engine

Engine specifications
Engine ModelC 18
Displacement1,105 in³
Power Measured @1,800 rpm
Gross Power700.0 hp
Net Power665.0 hp
Aspirationturbocharged

Dimensions

Dimensions specifications
Height - Top of Cab226 in
Length of Track on Ground204 in
Upper Structure Ground Clearance70 in
Length of Tracks254 in
Height of Tracks62 in

Undercarriage

Undercarriage specifications
Track Gauge166 in
Max Travel Speed1.5 mph
Number of Upper Rollers3
Number of Lower Rollers9
Backhoe Shoe Width 124 in
Backhoe Operating Weight - Shoe 1251,548 lb
Backhoe Ground Pressure - Shoe 124 psi
Number of Track Shoes per Side52
Tail Swing Radius169 in
Backhoe Shoe Width 230 in
Backhoe Ground Pressure - Shoe 219 psi
Backhoe Operating Weight - Shoe 2254,744 lb
Backhoe Shoe Width 336 in
Backhoe Ground Pressure - Shoe 316 psi
Backhoe Operating Weight - Shoe 3258,382 lb

Bucket

Bucket specifications
Reference Bucket Capacity7.90 yd³
Maximum Bucket Capacity9.19 yd³
Minimum Bucket Capacity7.90 yd³

Backhoe Boom / Stick 1

Backhoe Boom / Stick 1 specifications
Max Dig Depth236 in
Max Cutting Height493 in
Max Dump Height350 in
Max Reach on Ground476 in

Backhoe Boom / Stick 2

Backhoe Boom / Stick 2 specifications
Max Dig Depth288 in
Max Cutting Height504 in
Max Dump Height347 in
Max Reach on Ground521 in
