Terex
Caterpillar
5130B
Mini Excavator
16 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Fuel Capacity | 845.3 gal |
|---|---|
| Hydraulic System Fluid Capacity | 528.3 gal |
| Operating Voltage | 24 V |
| Swing Speed | 5 rpm |
Engine
| Engine Model | 2 x C18 |
|---|---|
| Displacement | 1,105 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 1,150.0 hp |
| Net Power | 1,104.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and charge air cooled |
Dimensions
| Height - Top of Cab | 258 in |
|---|---|
| Length of Track on Ground | 217 in |
| Upper Structure Ground Clearance | 80 in |
| Length of Tracks | 282 in |
| Height of Tracks | 76 in |
Undercarriage
| Track Gauge | 178 in |
|---|---|
| Max Travel Speed | 1.5 mph |
| Number of Upper Rollers | 2 |
| Loading Shovel Operating Weight | 379,195 lb |
| Loading Shovel Shoe Width | 32 in |
| Loading Shovel Ground Pressure | 25 psi |
| Number of Lower Rollers | 8 |
| Backhoe Shoe Width 1 | 32 in |
| Backhoe Operating Weight - Shoe 1 | 385,809 lb |
| Backhoe Ground Pressure - Shoe 1 | 26 psi |
| Number of Track Shoes per Side | 47 |
Bucket
| Reference Bucket Capacity | 10.50 yd³ |
|---|---|
| Maximum Bucket Capacity | 13.11 yd³ |
| Minimum Bucket Capacity | 10.50 yd³ |
Loading Shovel
| Max Dig Depth | 83 in |
|---|---|
| Max Dig Reach | 500 in |
| Max Cutting Height | 509 in |
| Max Dump Height | 398 in |
Backhoe Boom / Stick 1
| Max Dig Depth | 335 in |
|---|---|
| Max Cutting Height | 521 in |
