Hitachi
Caterpillar
5130B
Mini Excavator
16 specifications
1 / 5
Image 1 of 5
Specifications
58 data points
Operating Specifications
| Fuel Capacity | 1,093.6 gal |
|---|---|
| Hydraulic System Fluid Capacity | 581.1 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 140 A |
| Engine Oil Capacity | 43.9 gal |
| Cooling System Fluid Capacity | 104.4 gal |
| Swing Speed | 5 rpm |
Engine
| Engine Model | QSKTA38-CE |
|---|---|
| Displacement | 2,307 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 1,086.0 hp |
| Net Power | 1,039.0 hp |
| Number of Cylinders | 12 |
| Aspiration | turbocharged |
Dimensions
| Height - Top of Cab | 276 in |
|---|---|
| Length of Track on Ground | 228 in |
| Upper Structure Ground Clearance | 76 in |
| Length of Tracks | 295 in |
| Height of Tracks | 74 in |
Undercarriage
| Track Gauge | 181 in |
|---|---|
| Max Travel Speed | 1.8 mph |
| Number of Upper Rollers | 3 |
| Loading Shovel Operating Weight | 421,083 lb |
| Loading Shovel Shoe Width | 32 in |
| Loading Shovel Ground Pressure | 27 psi |
| Number of Lower Rollers | 8 |
| Backhoe Shoe Width 1 | 32 in |
| Backhoe Operating Weight - Shoe 1 | 423,288 lb |
| Backhoe Ground Pressure - Shoe 1 | 27 psi |
| Number of Track Shoes per Side | 49 |
| Tail Swing Radius | 238 in |
Bucket
| Reference Bucket Capacity | 14.40 yd³ |
|---|---|
| Maximum Bucket Capacity | 19.70 yd³ |
| Minimum Bucket Capacity | 14.40 yd³ |
Loading Shovel
| Max Dig Depth | 234 in |
|---|---|
| Max Dig Reach | 529 in |
| Max Cutting Height | 576 in |
| Max Dump Height | 411 in |
Backhoe Boom / Stick 1
| Max Dig Depth | 323 in |
|---|---|
| Max Cutting Height | 557 in |
| Max Dump Height | 357 in |
| Max Reach on Ground | 582 in |
| Max Vertical Wall Dig Depth | 219 in |
Backhoe Boom / Stick 2
| Max Dig Depth | 364 in |
|---|---|
| Max Cutting Height | 571 in |
| Max Dump Height | 362 in |
| Max Reach on Ground | 616 in |
| Max Vertical Wall Dig Depth | 261 in |
Backhoe Boom / Stick 3
| Max Dig Depth | 465 in |
|---|---|
| Max Cutting Height | 685 in |
| Max Dump Height | 466 in |
| Max Reach on Ground | 750 in |
| Max Vertical Wall Dig Depth | 396 in |
Backhoe Boom / Stick 4
| Max Dig Depth | 424 in |
|---|---|
| Max Cutting Height | 592 in |
| Max Dump Height | 386 in |
| Max Reach on Ground | 673 in |
| Max Vertical Wall Dig Depth | 293 in |
