Terex
Liugong
936E
Excavator
Specifications pending
1 / 5
Image 1 of 5
Specifications
34 data points
Operating Specifications
| Fuel Capacity | 50.2 gal |
|---|---|
| Hydraulic Pump Flow Capacity | 41.8 gal/min |
| Hydraulic System Fluid Capacity | 37.0 gal |
| Hydraulic System Relief Valve Pressure | 5,075 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 600 A |
Engine
| Engine Model | BF 4 M 2012 |
|---|---|
| Displacement | 246 in³ |
| Power Measured @ | 2,100 rpm |
| Aspiration | turbocharged |
Dimensions
| Ground Clearance | 17 in |
|---|---|
| Height - Top of Cab | 115 in |
| Length of Track on Ground | 103 in |
| Tail Swing Radius | 55 in |
| Width to Outside of Tracks | 100 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 79 in |
| Max Travel Speed | 3.4 mph |
| Shoe Size | 20 in |
| Drawbar Pull | 18,450 lb |
Boom/Stick Excavator Option 1
| Max Loading Height | 206 in |
|---|---|
| Max Vertical Wall Digging Depth | 110 in |
| Max Cutting Height | 288 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.71 yd³ |
| Minimum Bucket Capacity | 0.41 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 185 in |
|---|---|
| Max Vertical Wall Digging Depth | 124 in |
| Max Cutting Height | 300 in |
| Max Loading Height | 215 in |
| Max Reach Along Ground | 326 in |
| Shipping Length of Unit | 284 in |
| Shipping Height of Unit | 114 in |
