Terex
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 7,449 lb |
|---|---|
| Fuel Capacity | 8.0 gal |
| Hydraulic System Fluid Capacity | 2.7 gal |
| Tire Size | 12x16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 90 A |
| Engine Oil Fluid Capacity | 2.3 gal |
| Shipping Weight - Empty | 6,598 lb |
Engine
| Engine Model | Perkins 804D-33T |
|---|---|
| Displacement | 201 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 74.0 hp |
| Number of Cylinders | 4 |
| Max Torque | 181 lb-ft |
| Air cleaner | Dual Stage |
| Emissions Certification | Tier 3 |
Hydraulic System
| Pump Flow Capacity | 21.4 gal/min |
|---|---|
| Relief Valve Pressure | 3,335 psi |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Wheelbase | 49 in |
| Width Over Tires | 72 in |
| Height - Top of ROPS/FOPS | 83 in |
| Length with Bucket | 144 in |
| Length w/o Bucket | 108 in |
| Dump angle | 46 ° |
| Height to Hinge Pin | 125 in |
| Rear Departure Angle | 26 |
Loader
| Tipping load (ISO 14397) | 3,986 lb |
|---|
Axles
| Tractive Effort | 28,541 lb-ft |
|---|
