Terex
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 7,749 lb |
|---|---|
| Fuel Capacity | 29.9 gal |
| Hydraulic System Fluid Capacity | 10.1 gal |
| Tire Size | 12x16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 90 A |
| Engine Oil Fluid Capacity | 2.3 gal |
| Shipping Weight - Empty | 6,901 lb |
Engine
| Engine Model | 804D-33T |
|---|---|
| Displacement | 201 in³ |
| Gross Power | 83.0 hp |
| Number of Cylinders | 4 |
| Max Torque | 195 lb-ft |
| Engine Make | Perkins |
| Air cleaner | Dual Stage |
| Emissions Certification | Tier 4 |
Hydraulic System
| Relief Valve Pressure | 3,300 psi |
|---|---|
| Auxiliary hydraulic flow | 21.4 gal/min |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Wheelbase | 49 in |
| Width Over Tires | 73 in |
| Height - Top of ROPS/FOPS | 3 in |
| Length with Bucket | 145 in |
| Dump angle | 46 ° |
| Height to Hinge Pin | 125 in |
| Rear Departure Angle | 26 |
Loader
| Tipping load (ISO 14397) | 4,641 lb |
|---|---|
| bucket breakout force (ISO 14397) | 5,498 lb |
