Terex
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 6,986 lb |
|---|---|
| Max Speed | 12.0 mph |
| Fuel Capacity | 25.0 gal |
| Hydraulic System Fluid Capacity | 8.0 gal |
| Tire Size | 10X16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 65 A |
| Engine Oil Fluid Capacity | 2.9 gal |
| Shipping Weight - Empty | 6,261 lb |
Engine
| Engine Model | Perkins 404D-22T |
|---|---|
| Displacement | 134 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 60.0 hp |
| Number of Cylinders | 4 |
| Max Torque | 140 lb-ft |
| Emissions Certification | Tier 4 |
Hydraulic System
| Pump Flow Capacity | 17.2 gal/min |
|---|
Dimensions
| Wheelbase | 41 in |
|---|---|
| Width Over Tires | 67 in |
| Height - Top of ROPS/FOPS | 77 in |
| Length with Bucket | 137 in |
| Dump Ground Clearance | 11 in |
| Height to Hinge Pin | 118 in |
| Ground Clearance - Unloaded | 11 in |
Loader
| Operating Load Rating | 2,000 lb |
|---|---|
| Tipping load (ISO 14397) | 4,000 lb |
