Terex
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 8,680 lb |
|---|---|
| Max Speed | 12.0 mph |
| Fuel Capacity | 23.0 gal |
| Hydraulic System Fluid Capacity | 8.1 gal |
| Tire Size | 12 X 16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 90 A |
| Engine Oil Fluid Capacity | 2.3 gal |
| Shipping Weight - Empty | 8,384 lb |
Engine
| Engine Model | Cummins QSB 3.3 |
|---|---|
| Displacement | 201 in³ |
| Gross Power | 85.0 hp |
| Number of Cylinders | 4 |
| Max Torque | 195 lb-ft |
| Air cleaner | Dual Stage |
| Emissions Certification | Tier 4 |
Hydraulic System
| Pump Flow Capacity | 25.9 gal/min |
|---|---|
| Relief Valve Pressure | 3,335 psi |
Dimensions
| Wheelbase | 49 in |
|---|---|
| Width Over Tires | 73 in |
| Height - Top of ROPS/FOPS | 86 in |
| Length with Bucket | 146 in |
| Dump Ground Clearance | 11 in |
| Height to Hinge Pin | 131 in |
| Ground Clearance - Unloaded | 10 in |
Loader
| Operating Load Rating | 4,129 lb |
|---|---|
| Tipping load (ISO 14397) | 8,259 lb |
| bucket breakout force (ISO 14397) | 5,820 lb |
Axles
| Tractive Effort | 28,541 lb-ft |
|---|
