Terramite
Allmand
TLB 220
Backhoe Loader
24 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 3,025 lb |
|---|
Engine
| Net Power | 20.0 hp |
|---|
General Specifications
| Operating Weight lbs (kg) | 3,025 (1,372) Starting 2004 Model Year |
|---|---|
| Max Digging Depth ft. (m) | 8.3 (2.5) Starting 2009 Model Year |
| Lift Capacity lbs (kgs) | 1,700 (771) Starting 2004 Model Year |
| Loading Height ft (m) | 6.7 (2) Starting 2004 Model Year |
| 4th Gear Fwd mph (kmh) | hydrostatic Starting 2010 Model Year |
| Backhoe Loading Height ft. (m) | 6.3 (1.9) Starting 2009 Model Year |
| Travel Speed 4th Gear Fwd MPH (kmh) | - Starting 2009 Model Year |
| Breakout Force lbs (kgs) | 2,800 (1,270) Starting 2004 Model Year |
| Digging Depth ft (m) | 8.3 (2.5) Starting 2004 Model Year |
| Loader SAE HP (kw) | 20 (14.9) Starting 2009 Model Year |
| Loader Lift Capacity lbs. (kg) | 1,700 (771) Starting 2009 Model Year |
| Loader Breakout Force lbs. (kg) | 2,200 (998) Starting 2009 Model Year |
| SAE Net hp (kW) | 20 (14.9) Starting 2004 Model Year |
| SAE HP (KW) | 20 (1.5) Starting 2010 Model Year |
| Weight lbs (kg) | 3,100 (1,406) Starting 2010 Model Year |
Backhoe
| Dig Depth | 100 in |
|---|---|
| Load Height | 76 in |
Loader
| Lift Capacity | 1,700 lb |
|---|---|
| Bucket Breakout Force | 2,200 lb |
