Thomas
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 5,698 lb |
|---|---|
| Max Speed | 7.1 mph |
| Fuel Capacity | 20.0 gal |
| Hydraulic System Fluid Capacity | 17.2 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 70 A |
| Operating Speed | 7.1 mph |
Engine
| Engine Model | Turbo A2300 |
|---|---|
| Displacement | 140 in³ |
| Gross Power | 60.0 hp |
| Number of Cylinders | 4 |
Hydraulic System
| Pump Flow Capacity | 20.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Hydrostatic |
Dimensions
| Ground Clearance | 8 in |
|---|---|
| Height - Top of Cab | 898 in |
| Wheelbase | 497 in |
| Width Over Tires | 48 in |
| Reach at Max Lift and Dump | 27 in |
| Length with Bucket | 1,559 in |
| Clearance at Max Lift and Dump | 84 in |
| Turning Radius from Center - inc bucket | 97 in |
| Turning Radius from Center - machine rear | 50 in |
| Length w/o Bucket | 1,209 in |
Loader
| Operating Load Rating | 1,500 lb |
|---|---|
| Tipping Angle | 2,992 ° |
| Breakout Force | 4,150 psi |
