Thomas
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 7,200 lb |
|---|---|
| Max Speed | 7.8 mph |
| Fuel Capacity | 21.2 gal |
| Hydraulic System Fluid Capacity | 17.5 gal |
| Tire Size | 12.00x16.5 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
Engine
| Engine Model | V2003MT Turbo |
|---|---|
| Displacement | 122 in³ |
| Power Measured @ | 2,800 rpm |
| Aspiration | turbocharged |
Hydraulic System
| Pump Flow Capacity | 20.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 84 in |
| Wheelbase | 43 in |
| Width Over Tires | 69 in |
| Reach at Max Lift and Dump | 32 in |
| Length with Bucket | 141 in |
| Clearance at Max Lift and Dump | 96 in |
| Turning Radius from Center - inc bucket | 42 in |
| Turning Radius from Center - machine rear | 34 in |
| Length w/o Bucket | 113 in |
Loader
| Operating Load Rating | 2,100 lb |
|---|---|
| Breakout Force | 4,900 psi |
