Thomas
Case
440
Skid Steer Loader
32 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 8,000 lb |
|---|---|
| Max Speed | 12.1 mph |
| Fuel Capacity | 28.7 gal |
| Hydraulic System Fluid Capacity | 24.0 gal |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 60 A |
Engine
| Engine Model | V3300T Turbo |
|---|---|
| Displacement | 203 in³ |
| Power Measured @ | 2,750 rpm |
| Gross Power | 87.4 hp |
| Number of Cylinders | 4 |
| Aspiration | Turbocharged |
Hydraulic System
| Pump Flow Capacity | 21.0 gal/min |
|---|---|
| Relief Valve Pressure | 3,000 psi |
| Pump Type | Hydrostatic |
Dimensions
| Ground Clearance | 9 in |
|---|---|
| Height - Top of Cab | 84 in |
| Wheelbase | 49 in |
| Width Over Tires | 71 in |
| Reach at Max Lift and Dump | 22 in |
| Length with Bucket | 146 in |
| Clearance at Max Lift and Dump | 97 in |
| Turning Radius from Center - inc bucket | 84 in |
| Turning Radius from Center - machine rear | 70 in |
| Length w/o Bucket | 118 in |
Loader
| Operating Load Rating | 2,500 lb |
|---|---|
| Tipping Angle | 5,000 ° |
| Breakout Force | 4,450 psi |
