Tigercat

H860C

Processor

Operating Weight
60,900 lb
Lift Capacity at Max Reach
11,817 lb
Gross Power
300.0 hp
All processors/harvesters
Tigercat H860C Processor
1 / 5
Image 1 of 5
Image: tigercat.com

Specifications

17 data points

Operating Specifications

Operating Specifications specifications
Operating Weight60,900 lb
Fuel Capacity256.3 gal
Operating Voltage24 V
Alternator Supplied Amperage110 A
Hydraulic System Fluid Capacity50.2 gal

Engine

Engine specifications
Engine ModelQSL9
Power Measured @1,800 rpm
Gross Power300.0 hp

Dimensions

Dimensions specifications
Height - Top of Cab131 in
Overall Width130 in

Undercarriage

Undercarriage specifications
Number of Track Rollers per Side8
Shoe Size24 in
Track Pitch8 in
Ground Clearance29 in
Track Length175 in

Boom

Boom specifications
Lift Capacity at Max Reach11,817 lb
Max Reach w/ Head371 in
