Tong Yang Mooslan
Fendt
209 VA
Tractor
19 specifications
Tong Yang Mooslan
T1003
- Operating Weight
- 8,124 lb
- Displacement
- 268 in³
- Power Measured @
- 2,200 rpm
- Gross Power
- 99.2 hp
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 8,124 lb |
|---|---|
| Fuel Capacity | 33.1 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 5,490 lb |
| 3 Point Hitch Type | Cat II |
| Turning Radius | 146 in |
| Alternator Supplied Amperage | 80 A |
| Operating Voltage | 12 V |
| Cooling System Fluid Capacity | 3.0 gal |
| Hydraulic System Fluid Capacity | 19.9 gal |
| Engine Oil Capacity | 1.8 gal |
Engine
| Engine Model | 3054C-DIT |
|---|---|
| Displacement | 268 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 99.2 hp |
| Number of Cylinders | 4 |
| PTO Power | 88.2 hp |
Hydraulic System
| Pump Flow Capacity | 22.1 gal/min |
|---|---|
| Number of Remote Control Valves | 3 |
Dimensions
| Height - Top of Cab | 108 in |
|---|---|
| Wheelbase | 91 in |
| Overall Length | 14 in |
| Tire Size | front 13.6-24-8PR rear 16.9-34-8PR |
| Width Outside Frame | 89 in |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Number of Forward Gears | 32 |
| Transmission Type | sync/power shuttle |
| Number of Reverse Gears | 32 |
