Toyota
Komatsu
FG25T-12
Forklift
32 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 10,185 lb |
|---|---|
| Max Speed | 9.9 mph |
| Drawbar Pull | 2,560 lb |
| Hydraulic System Relief Valve Pressure | 2,000 psi |
Dimensions
| Wheelbase | 52 in |
|---|---|
| Overall Width | 43 in |
| Overall Height - mast lowered | 78 in |
| Length to Fork Face | 53 in |
| Gradeability | 27.0 % |
| Max Fork Height | 120 in |
| Turning Radius - Outside | 59 in |
| Front Wheel Tread Width | 36 in |
| Rear Wheel tread Width - max | 7 in |
| Free lift | 6 in |
| Undercarriage Width | 36 in |
Tires & Wheels
| Rear Tires Size | Pneumatic |
|---|---|
| Front Tires Size | Pneumatic |
| Steering Tire Size | 16 x 6-8-10PR |
Mast
| Load Capacity | 3,000 lb |
|---|---|
| Lift Speed | 1.1 mph |
| Lower Speed | 1.2 mph |
Electrical System
| Battery capacity | 375 Ah |
|---|---|
| Battery voltage | 595 Ah |
| Control Load Handling | MOSFET Transistor |
| Battery Length | 22 in |
| Battery Width | 39 in |
| Battery Height | 25 in |
| Battery Weight | 1,543 lb |
