Toyota
Komatsu
FB15M-3
Forklift
22 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 5,886 lb |
|---|---|
| Max Speed | 10.9 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Cushion |
| Fuel Capacity | 7.2 gal |
| Hydraulic System Relief Valve Pressure | 2,275 psi |
| Auxiliary hydraulic flow | 16.0 gal/min |
Engine
| Engine Model | 1FS |
|---|---|
| Displacement | 224 in³ |
| Power Measured @ | 2,350 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 1,400 rpm |
| Engine Make | TOYOTA |
| Power | 84.0 hp |
| Torque | 214 lb-ft |
Dimensions
| Overall Width | 50 in |
|---|---|
| Turning Radius | 90 in |
| Length to Fork Face | 104 in |
| Gradeability | 47.0 % |
| Max Fork Height | 121 in |
| Free lift | 4 in |
| Forward Tilt | 5 ° |
| Fork Spread Max | 47 in |
| Fork Spread Min-outer edge to edge | 12 in |
Transmission
| Transmission Type | Power shift |
|---|---|
| Speed ranges (forwards/backward) | 1 |
Mast
| Load Capacity | 7,716 lb |
|---|---|
| Load Center | 24 in |
| Lift height- largest mast | 168 in |
| Lift height-smallest mast | 81 in |
Electrical System
| Battery | 12 V /48 Ah |
|---|
