Toyota
Komatsu
FB15M-3
Forklift
22 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 5,886 lb |
|---|---|
| Max Speed | 10.9 mph |
| Number of Front Wheels | 2 |
| Number of Rear Wheels | 2 |
| Tire Type | Cushion |
| Fuel Capacity | 7.2 gal |
| Hydraulic System Relief Valve Pressure | 2,275 psi |
| Auxiliary hydraulic flow | 16.0 gal/min |
Engine
| Engine Model | 4Y-ECS |
|---|---|
| Displacement | 136 in³ |
| Power Measured @ | 2,250 rpm |
| Number of Cylinders | 4 |
| Torque Measured @ | 2,100 rpm |
| Engine Make | TOYOTA |
| Power | 48.0 hp |
| Torque | 118 lb-ft |
Dimensions
| Ground Clearance | 3 in |
|---|---|
| Overall Width | 39 in |
| Turning Radius | 69 in |
| Length to Fork Face | 83 in |
| Height to Top of Overhead Guard | 80 in |
| Max Fork Height | 132 in |
Transmission
| Transmission Type | Power shift |
|---|---|
| Speed ranges (forwards/backward) | 1 |
Mast
| Load Capacity | 2,976 lb |
|---|---|
| Load Center | 24 in |
