Upright

SB47JRT

Aerial Lift

Max Platform Height
559 in
Overall Length
27 in
Overall Width
95 in
All aerial lifts
Upright SB47JRT Aerial Lift
1 / 5
Image 1 of 5
Image: atermonas.com

Specifications

18 data points

Engine

Engine specifications
Engine ModelF3L-2011
Gross Power48.0 hp
Fuel Typediesel

Dimensions

Dimensions specifications
Ground Clearance10 in
Overall Length27 in
Overall Width95 in
Overall Height - mast lowered95 in

Performance

Performance specifications
Operating Weight13,499 lb
Max Speed3.0 mph
Tire Size12 x 16.5
Tire Fill/Typepoly filled/lug

Platform

Platform specifications
Max Platform Height559 in
Max Platform Weight Capacity500 lb
Platform Inner Length60 in
Platform Inner Width30 in
Max Working Height639 in
Max Horizontal Reach469 in
Platform Rotation170 °
