Ursus
Fendt
209 VA
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 8,609 lb |
|---|---|
| Fuel Capacity | 47.6 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 8,488 lb |
Engine
| Engine Model | 1104C-44 |
|---|---|
| Displacement | 269 in³ |
| Gross Power | 80.5 hp |
| Number of Cylinders | 4 |
| PTO Power | 65.0 hp |
Hydraulic System
| Pump Flow Capacity | 15.9 gal/min |
|---|
Dimensions
| Height - Top of Cab | 108 in |
|---|---|
| Wheelbase | 91 in |
| Overall Length | 14 in |
| Tire Size | front 12.4R24 rear 16.9R34 |
| Width Outside Frame | 827 in |
Transmission
| Max Speed | 18.6 mph |
|---|---|
| Number of Forward Gears | 12 |
| Transmission Type | mechanical with constant mesh gears |
| Number of Reverse Gears | 4 |
