Versatile
Mccormick
MTX135
Tractor
19 specifications
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight | 22,000 lb |
|---|---|
| Fuel Capacity | 120.0 gal |
| 3 Point Hitch Type | 3 3N/2 |
| Cooling System Fluid Capacity | 11.0 gal |
| Hydraulic System Fluid Capacity | 21.0 gal |
| Engine Oil Capacity | 6.5 gal |
| Front Tire Size | 18.4x38 |
| Rear Tire Size | 18.4x38 |
Engine
| Engine Model | VT-555-C |
|---|---|
| Displacement | 555 in³ |
| Gross Power | 210.0 hp |
| Number of Cylinders | 8 |
| Aspiration | Turbocharged |
| Engine Make | Cummins |
| PTO Power | 182.0 hp |
Hydraulic System
| Pump Flow Capacity | 23.2 gal/min |
|---|---|
| Number of Remote Control Valves | 3 |
| Hydraulic System Type | Open-center |
Dimensions
| Wheelbase | 120 in |
|---|---|
| Overall Length | 253 in |
Transmission
| Max Speed - Reverse | 5.5 mph |
|---|---|
| Max Speed - Forward | 17.3 mph |
| Number of Forward Gears | 15 |
| Number of Reverse Gears | 5 |
