Case IH
Fendt
817
Tractor
23 specifications
1 / 5
Image 1 of 5
Specifications
21 data points
Operating Specifications
| Operating Weight | 13,448 lb |
|---|---|
| Fuel Capacity | 71.0 gal |
| 3 Point Hitch Lift Capacity @ 24 inches | 7,901 lb |
| Alternator Supplied Amperage | 150 A |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 19.5 gal |
| Engine Oil Capacity | 16.0 gal |
| DEF tank capacity | 12.7 gal |
Engine
| Displacement | 409 in³ |
|---|---|
| Gross Power | 146.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Cross-Flow Aspiration / Turbocharged |
| PTO Power | 120.0 hp |
Hydraulic System
| Pump Flow Capacity | 26.5 gal/min |
|---|---|
| Number of Remote Control Valves | 2 |
| Pump Type | Closed Center Pressure Flow Compensating |
Transmission
| Max Speed | 24.9 mph |
|---|---|
| Number of Forward Gears | 18 |
| Number of Reverse Gears | 6 |
Production
| Series | Puma Series |
|---|---|
| Years Manufactured | 2,011 – 2,013 |
Comparable machines
Other tractors in a similar weight class.
