Vibromax
265
Smooth Drum Roller
18 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 10,141 lb |
|---|---|
| Max Speed | 7.9 mph |
| Fuel Capacity | 47.6 gal |
| Operating Width | 60 in |
| Operating Voltage | 12 V |
| Hydraulic System Fluid Capacity | 15.9 gal |
| Engine Oil Capacity | 2.2 gal |
| Alternator Supplied Amperage | 60 A |
| Cooling System Fluid Capacity | 3.7 gal |
Engine
| Engine Model | B 3.3 |
|---|---|
| Displacement | 199 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 60.4 hp |
| Make | Cummins |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 104 in |
| Wheelbase | 7 in |
| Overall Length | 14 in |
| Turning Radius - Inside | 122 in |
Tires & Wheels
| Tires | 12.00R20 XZL |
|---|
Drum
| Drum Diameter | 39 in |
|---|---|
| Vibration Frequency 1 | 32 vpm |
| Static Linear Load | 7 lb-ft |
| Vibration Frequency | 1,920 vpm |
| Nominal Amplitude - Med | 0 in |
| Centrifugal Force - MEd | 22,841 lb |
