Hamm
HD 10 VO
Smooth Drum Roller
40 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 6,085 lb |
|---|---|
| Max Speed | 6.9 mph |
| Fuel Capacity | 16.7 gal |
| Operating Voltage | 12 V |
Engine
| Engine Model | D140B |
|---|---|
| Displacement | 85 in³ |
| Power Measured @ | 2,800 rpm |
| Net Power | 29.0 hp |
Dimensions
| Ground Clearance | 11 in |
|---|---|
| Height - Top of Cab | 69 in |
| Wheelbase | 6 in |
| Overall Length | 8 in |
Drum
| Drum Width | 47 in |
|---|---|
| Drum Diameter | 28 in |
| Vibration Frequency 1 | 58 vpm |
| Static Linear Load | 5 lb-ft |
| Nominal Amplitude - Med | 0 in |
| Centrifugal Force - MEd | 8,100 lb |
