Volvo
John Deere
250D II
Off-Highway Truck
5 specifications
1 / 5
Image 1 of 5
Specifications
44 data points
Operating Specifications
| Fuel Capacity | 106.0 gal |
|---|---|
| Tire Size | 235R25 |
| Engine Oil Capacity | 10.6 gal |
| Cooling System Fluid Capacity | 30.4 gal |
| Hydraulic System Fluid Capacity | 46.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
| Transmission Fluid Capacity | 11.0 gal |
Engine
| Engine Model | D9B ABE3 |
|---|---|
| Displacement | 574 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 300.0 hp |
| Net Power | 299.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharged and Intercooled |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 1,254 lb-ft |
| Make | Volvo |
Weights
| Operating Weight | 42,924 lb |
|---|---|
| Total Empty | 47,531 lb |
| Front Axle - empty | 26,808 lb |
| Total Loaded | 100,442 lb |
| Rear Axle - empty | 20,723 lb |
| Front Axle - loaded | 31,173 lb |
| Rear Axle - loaded | 69,269 lb |
Dimensions
| Ground Clearance | 26 in |
|---|---|
| Wheelbase | 165 in |
| Overall Length | 403 in |
| Overall Width | 107 in |
| Overall Height | 128 in |
| Dump Height | 259 in |
| Dump Ground Clearance | 28 in |
Transmission
| Max Speed | 32.9 mph |
|---|---|
| Transmission Type | Volvo PowerTronic planetary transmission |
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 2 |
Drive System
| Drive Config | 4X4 |
|---|
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 52,910 lb |
|---|---|
| Dump Angle | 72 ° |
| Raise Time | 12.0 s |
| Lower Time | 9.0 s |
| Capacity - Heaped | 19.59 yd³ |
| Capacity - Struck | 15.30 yd³ |
